try the other side sometimes there is a insert for a tool there too
3AmigosMan on
Get a #3 Easy-Out. If that fails, simply drill the head off to release the pressure. The axle should thread out easily afterwards.
ChickenTendies0 on
I saved boxxer fork and wheel thanks to, what I believe was, t30 or t40 torx bit. Mofo was baked together so good, that when it finally let go, I felt the smell of burned gun powder.
You need to prop the other side of the axle good, as to not damage anything and hammer it in good, because otherwise you will just strip the aluminum.
If you know that it’s not over tightened and sized on, use extractor bit as it’s a safer option
Mammonite on
Sorry off topic.
I hate those effin Newman axle, they are so bad. You have a Cube bike I guess?
cndvsn on
Other side
LaurensVanR on
Does the axle not have a hex on the other side as well? Extractors usually such, i’d hammer a torx or flathead in…
Chruisser on
Yea get yourself a torx bit set with several sizes. You should be able to get that out no problem.
There are easy outs that might work too.
Worse case scenario, you can drill the head out carefully. After that you’ll need to extract and remove the axle which could be tedious. I’ve found a well drilled hole, smaller than the axle size, with an ez out, works best in those cases.
Good luck, hopefully the torx does the trick.
tire_falafel on
If it’s a hex, the first step could be taking a torx in the next bigger size and hammering it in until its tight enough to turn.
Obviously you’ll have to replace the axle after.
Namerunaunyaroo on
Dunno but stop leaning on it.
Or get a torque wrench
Tuanzebeee on
Don’t use the easy out, in my experience they just chew up the metal and don’t grip it. Carefully hammering in a flathead screwdriver worked a charm for me
sanmarcoh on
Have you tried getting a thick elastic band and either allen key or better if you have it a torx? You might need to use a bit of force to get it in, but the elastic band can give the traction you need!
Playful-Awareness-15 on
EZ-Out…
OGwigglesrewind on
Order a replacement thru axle then use an easy out to remove it one last time and throw it away. Might wanna get some new high quality Allen’s if it’s not old so it doesn’t happen with the new one
WillBott44 on
New bike day!!!
deepstrut on
something called an “easy out” which is a tapered square that you hammer into the stripped bolt head, fucking up the material even more to get some bite.
once you do this, you can never use that axle again.
this looks too stripped to be hammering in a torx. i would use a proper easy out as they have more bite.
Ornery-Ad-2666 on
First order yourself a replacement through axle.
I would try in the following order:
1. Try hammering in torx bit
2. Try bolt extractor/ ez out
3. Use dremel to cut slot for flathead
4. Drill it out (find out thread size and use a drill that is smaller than the minor diameter of male thread). You don’t want to mess this up as it could ruin your frame. I would take it to a shop if not confident in doing on your own. Not easy to do while it’s attached to the trainer. Drilling the hole perfectly aligned is no easy task. I have done it many times in low risk scenarios. I would be very nervous doing it to my frame.
If all else fails congrats you’ve got a dedicated trainer.
19 Comments
You want an extractor bit.
And then you’ll need a new through axle.
Could try hammering a torx bit in then turn it
try the other side sometimes there is a insert for a tool there too
Get a #3 Easy-Out. If that fails, simply drill the head off to release the pressure. The axle should thread out easily afterwards.
I saved boxxer fork and wheel thanks to, what I believe was, t30 or t40 torx bit. Mofo was baked together so good, that when it finally let go, I felt the smell of burned gun powder.
You need to prop the other side of the axle good, as to not damage anything and hammer it in good, because otherwise you will just strip the aluminum.
If you know that it’s not over tightened and sized on, use extractor bit as it’s a safer option
Sorry off topic.
I hate those effin Newman axle, they are so bad. You have a Cube bike I guess?
Other side
Does the axle not have a hex on the other side as well? Extractors usually such, i’d hammer a torx or flathead in…
Yea get yourself a torx bit set with several sizes. You should be able to get that out no problem.
There are easy outs that might work too.
Worse case scenario, you can drill the head out carefully. After that you’ll need to extract and remove the axle which could be tedious. I’ve found a well drilled hole, smaller than the axle size, with an ez out, works best in those cases.
Good luck, hopefully the torx does the trick.
If it’s a hex, the first step could be taking a torx in the next bigger size and hammering it in until its tight enough to turn.
Obviously you’ll have to replace the axle after.
Dunno but stop leaning on it.
Or get a torque wrench
Don’t use the easy out, in my experience they just chew up the metal and don’t grip it. Carefully hammering in a flathead screwdriver worked a charm for me
Have you tried getting a thick elastic band and either allen key or better if you have it a torx? You might need to use a bit of force to get it in, but the elastic band can give the traction you need!
EZ-Out…
Order a replacement thru axle then use an easy out to remove it one last time and throw it away. Might wanna get some new high quality Allen’s if it’s not old so it doesn’t happen with the new one
New bike day!!!
something called an “easy out” which is a tapered square that you hammer into the stripped bolt head, fucking up the material even more to get some bite.
once you do this, you can never use that axle again.
this looks too stripped to be hammering in a torx. i would use a proper easy out as they have more bite.
First order yourself a replacement through axle.
I would try in the following order:
1. Try hammering in torx bit
2. Try bolt extractor/ ez out
3. Use dremel to cut slot for flathead
4. Drill it out (find out thread size and use a drill that is smaller than the minor diameter of male thread). You don’t want to mess this up as it could ruin your frame. I would take it to a shop if not confident in doing on your own. Not easy to do while it’s attached to the trainer. Drilling the hole perfectly aligned is no easy task. I have done it many times in low risk scenarios. I would be very nervous doing it to my frame.
If all else fails congrats you’ve got a dedicated trainer.
That’s your training bike now
