I have a 1st gen Canyon Lux Trail with a Fox 34 SC 120 fork. I’m considering over-forking to 130, with the main purpose to slacken the headtube/extend the wheelbase to make the bike a bit more stable. According to [bike-stats.de](https://bike-stats.de), that is going to slacken head (and seat) tube angles by 0.6 degrees and lengthen wheelbase by 5.4 mm, along with various other knock-on effects. My question is, if my goal is to make my bike a bit more stable and capable, is this change reasonable and worth it? The sag I run is 20% in the front and 30% in the rear (110 travel rear). Assuming I use stem length, headset spacers, and saddle position to maintain my cockpit, can I expect any noticeable difference in handling? At sag, I’d only be extending the fork length by 8 mm.
The other option I should consider is a new frame, but cost considerations favor a fork replacement rather than a frame replacement. But would I be better off with spending the extra money on the frame rather than the fork?
by Dependent-Bear-7714
5 Comments
10mm is okay. You may not even notice the difference. But do be warned that you may not have warranty
You can just get a [tapered angle-spacer](https://reverse-components.com/en/products/05%C2%B0-angle-spacer-tapered-forks) to slacken the headtube by 0.5°. Remove 10mm of spacers under the stem and your cockpit will end up in roughly the same position.
Much cheaper than a new fork or frame.
I think you can run 15% sag in the 34sc, I would try that first. See what sag you can run in the rear too, if you can go to 25%, do it.
Modern geometry (more reach, higher stack) will give you a more stable and capable bike than 10mm of travel or 0.6 degrees on the HTA will do, in my opinion. I’d say new bike/frame or leave it as is.
Yep, lots of people do this and it’s a great way to achieve the goals your looking for.
Generally, you don’t need a new fork, just a longer air shaft.
Also, most bikes are warrantied to run an extra 10mm of travel. Contact your manufacturer to find out.
